Datasheet

TD5.0

P/N	Polarity	IF(mA)	Color	λD (nm)	IV (mcd)	VF (V)
P/N	Polarity	IF(mA)	Color	λD (nm)	IV (mcd)	typ.	max
INND-TD50YGAG	Common Anode	25	Yellow Green	570	15	2	2.8
INND-TD50YGCG	Common Cathode	25	Yellow Green	570	15	2	2.8
INND-TD50YAG	Common Anode	25	Yellow	590	50	2	2.8
INND-TD50YCG	Common Cathode	25	Yellow	590	50	2	2.8
INND-TD50AAG	Common Anode	25	Amber	605	70	2	2.8
INND-TD50ACG	Common Cathode	25	Amber	605	70	2	2.8
INND-TD50RAG	Common Anode	25	Red	630	30	2	2.8
INND-TD50RCG	Common Cathode	25	Red	630	30	2	2.8
INND-TD50DRAG	Common Anode	25	Deep Red	645	25	2	2.8
INND-TD50DRCG	Common Cathode	25	Deep Red	645	25	2	2.8
INND-TD50GAG	Common Anode	30	Green	525	218	3.2	3.8
INND-TD50GCG	Common Cathode	30	Green	525	218	3.2	3.8
INND-TD50BAG	Common Anode	30	Blue	465	18	3.2	3.8
INND-TD50BCG	Common Cathode	30	Blue	465	18	3.2	3.8
INND-TD50WAG	Common Anode	30	White	X:0.27	120	3.2	3.8
INND-TD50WCG	Common Cathode	30	White	Y:0.25	120	3.2	3.8
