| Product | Color | λ (nm) | IF (mA) | IV (mcd) | VA 2θ1/2 | VF (V) | Lens Color |
|---|---|---|---|---|---|---|---|
| max | |||||||
| INP-3A4R40 | Red | 624 | 20 | 2500 | 40 | 2.4 | W.C. |
| INP-3A4C40 | Cyan | 505 | 20 | 8000 | 40 | 3.6 | W.C. |
| INP-3A4G40 | Green | 525 | 20 | 8000 | 40 | 3.6 | W.C. |
| INP-3A4Y40 | Yellow | 590 | 20 | 2500 | 40 | 2.4 | W.C. |
| INP-3A4A40 | Amber | 605 | 20 | 2500 | 40 | 2.4 | W.C. |
| INP-3A4B40 | Blue | 470 | 20 | 3000 | 40 | 3.6 | W.C. |
| INP-3A4W40.65 | Cool White | 6500K x=0.31, y=0.32 |
20 | 4000 | 40 | 3.6 | W.C. |
